Digital Living Network Alliance

Digital Living Network Alliance (DLNA) (originally named Digital Home Working Group [DHWG]) was founded by a group of consumer electronics companies to develop and promote a set of interoperability guidelines for sharing digital media among multimedia devices. As of June 2015 the organization claims membership of "more than 200 companies".

The group published its first set of guidelines in June 2004. The guidelines incorporate several existing public standards, including Universal Plug and Play (UPnP) for media management and device discovery and control, and widely used digital media formats and wired and wireless networking standards.

As of October 2014, over 25,000 different device models have obtained "DLNA Certified" status, indicated by a logo on their packaging and confirming their interoperability with other devices. It was estimated that by 2014 nearly 3 billion DLNA-certified devices, from digital cameras to game consoles and TVs, were installed in users' homes.

History

Sony established the DLNA in June 2003 as the Digital Home Working Group, changing its name 12 months later, when the first set of guidelines for DLNA was published. Home Networked Device Interoperability Guidelines v1.5 was published in March 2006 and expanded in October of the same year; the changes included the addition of two new product categories — printers, and mobile devices — as well as an "increase of DLNA Device Classes from two to twelve" and an increase in supported user scenarios related to the new product categories.

Specification

The DLNA Certified Device Classes are separated as follows:

Home Network Devices

  • Digital Media Server (DMS): store content and make it available to networked digital media players (DMP) and digital media renderers (DMR). Examples include PCs and network-attached storage (NAS) devices.
  • Digital Media Player (DMP): find content on digital media servers (DMS) and provide playback and rendering capabilities. Examples include TVs, stereos and home theaters, wireless monitors and game consoles.
  • Digital Media Renderer (DMR): play content as instructed by a digital media controller (DMC), which will find content from a digital media server (DMS). Examples include TVs, audio/video receivers, video displays and remote speakers for music. It is possible for a single device (e.g. TV, A/V receiver, etc.) to function both as a DMR (receives "pushed" content from DMS) and DMP ("pulls" content from DMS)
  • Digital Media Controller (DMC): find content on digital media servers (DMS) and instruct digital media renderers (DMR) to play the content. Content doesn't stream from or through the DMC. Examples include Internet tablets, Wi-Fi enabled digital cameras and smartphones.
  • Generally, digital media players (DMP) and digital media controllers (DMC) with print capability can print to DMPr. Examples include networked photo printers and networked all-in-one printers

Mobile Handheld Devices

  • Mobile Digital Media Server (M-DMS): store content and make it available to wired/wireless networked mobile digital media players (M-DMP), and digital media renderers. Examples include mobile phones and portable music players.
  • Mobile Digital Media Player (M-DMP): find and play content on a digital media server (DMS) or mobile digital media server (M-DMS). Examples include mobile phones and mobile media tablets designed for viewing multimedia content.
  • Mobile Digital Media Uploader (M-DMU): send (upload) content to a digital media server (DMS) or mobile digital media server (M-DMS). Examples include digital cameras and mobile phones.
  • Mobile Digital Media Downloader (M-DMD): find and store (download) content from a digital media server (DMS) or mobile digital media server (M-DMS). Examples include portable music players and mobile phones.
  • Mobile Digital Media Controller (M-DMC): find content on a digital media server (DMS) or mobile digital media server (M-DMS) and send it to digital media renderers (DMR). Examples include personal digital assistants (PDAs) and mobile phones.

Home Infrastructure Devices

  • Mobile Network Connectivity Function (M-NCF): provide a bridge between mobile handheld device network connectivity and home network connectivity.
  • Media Interoperability Unit (MIU): provide content transformation between required media formats for home network and mobile handheld devices.

The specification uses DTCP-IP as "link protection" for copyright-protected commercial content between one device to another.

Member companies

As of February 2014, there are 17 promoter members and 215 contributor members. The promoter members are:

ACCESS, Arris, Awox, Broadcom, CableLabs, Comcast, Dolby Laboratories, DTS, Intel, LG Electronics, Microsoft, Nokia, Panasonic, Samsung Electronics, Sony Electronics, Time Warner Cable, and Verizon.

Apple is not a member. Apple uses its own proprietary Digital Audio Access Protocol instead of DLNA's UPnP protocols.

DLNA is run by a board of directors consisting of 9 members. There are 8 permanent representatives from the following companies: Broadcom, Intel, Microsoft, Nokia, Samsung Electronics, Sony Electronics, CableLabs, AwoX  and one elected by the promoter members.

The board of directors oversees the activity of the four following committees:

  • Ecosystem Committee, planning the future development of DLNA guidelines
  • Compliance & Test Committee, overseeing the certification program and its evolutions
  • Marketing Communication Advisory Council, actively promoting DLNA worldwide
  • Technical Committee, writing the DLNA guidelines

Products supporting DLNA

DLNA-certified devices

There are over nine thousand products on the market that are DLNA Certified. This includes TVs, DVD and Blu-ray players, games consoles, digital media players, photo frames, cameras, NAS devices, PCs, mobile handsets, and more. According to a study from Parks Associates, nearly 3 billion products are on the market in 2014 reaching up to over 7 billion by 2018. Consumers can see if their product is certified by looking for a DLNA logo on the device or by verifying certification through the DLNA Product Search.

Manufacturers can seek certification testing from a DLNA Accredited Independent Certification Vendor such as the UNH InterOperability Laboratory, Allion Labs, CESI Technology Co., Digital TV Labs, XXCAL or Testronic.

DLNA technology components

As the past president of DLNA pointed out to the Register in March 2009:

The vendors of software are allowed to claim that their software is a DLNA Technology Component if the software has gone through certification testing on a device and the device has been granted DLNA Certification. DLNA Technology Components are not marketed to the consumer but only to industry.

DLNA Interoperability Guidelines allow manufacturers to participate in the growing marketplace of networked devices and are separated into the below sections of key technology components.

  • Network and Connectivity
  • Device and Service Discovery and Control
  • Media Format and Transport Model
  • Media Management, Distribution and Control
  • Digital Rights Management and Content Protection
  • Manageability

DLNA-certified software

In 2005, DLNA began a Software Certification program in order to make it easier for consumers to share their digital media across a broader range of products. DLNA is certifying software that is sold directly to consumers through retailers, websites and mobile application stores. With DLNA Certified software, consumers can upgrade products from within their home networks that may not be DLNA Certified and bring them into their personal DLNA ecosystems. This helps in bringing content such as videos, photos and music stored on DLNA Certified devices to a larger selection of consumer electronics, mobile and PC products.

DLNA-certified products

Some examples:



  • AwoX mediaCTRL is a commercial server. It is based on AwoX DLNA Technology component software development kits.
  • CyberLink SoftDMA 2. Appears to be just a DMP.
  • Most Smartphones share multimedia including music, pictures or videos.
  • Microsoft Xbox 360 is a DLNA Certified DMP.
  • Sony PlayStation 3 is a DLNA Certified DMP.



Servers

Main article: Comparison of UPnP AV MediaServers

  • Asset UPnP (DLNA compatible) from Illustrate. An audio specific UPnP/DLNA server for Windows (including Windows Home Server), QNAP, Apple OS X (Mountain Lion or newer), Debian Linux and Raspberry Pi. Features music library, album art, audio WAVE/LPCM transcoding from a huge range of audio codecs, ReplayGain, support for streaming audio in many formats including lossless Flac, Wav, MP3 and playlists, and a customizable browse tree. Companion products "dBpoweramp CD Ripper" for CD ripping and "dBpoweramp Music Converter" for converting digital music formats can be used in compiling a digital music library.
  • CyberLink Media Server 2. Appears to be just a DMS.
  • Home Media Center, a free and open source media server compatible with DLNA. Includes web interface for streaming content to web browser (Android, iOS, …), subtitles integration and Windows desktop streaming. This server is easy to use.
  • Jamcast, a DLNA compliant media server for MS Windows that is capable of streaming any audio playing on the PC to DLNA devices.
  • JRiver Media Center, DLNA media server for Windows or Mac. Also includes Renderer and Controller.
  • Mezzmo is a feature-packed UPnP/DLNA media server with on-the-fly transcoding and media organizing features.
  • PlayOn from MediaMall appears to be a DMS, also capable of serving streamed internet media such as Netflix, Hulu, Google YouTube, CNN, ESPN.
  • PS3 Media Server, an open source (GPLv2) DLNA compliant UPnP Media Server for the Sony PS3, written in Java, with the purpose of streaming or transcoding any kind of media files, with minimum configuration.
  • Serviio is a UPnP/DLNA media server and works with any DLNA compliant device with the purpose of streaming or transcoding any kind of media files (TV, Sony PlayStation 3, etc.) and some other (MS Xbox 360). Frequently updated, has a good support community. Available on Windows, Apple Mac OSX, Linux and Synology NAS platforms.
  • Subsonic (media server) Media Server
  • TwonkyMedia server runs on Windows, Mac OS X, GNU/Linux and Android and enables media sharing of local and online media among a large variety of devices.
  • TVMOBiLi – A shareware DLNA/UPnP Media Server for MS Windows, Apple Mac OS X and GNU/Linux. Appears to be just a DMS.
  • TVersity, a DLNA MediaServer with strong device support and on-the-fly transcoding. Appears to be just a DMS.
  • Wild Media Server (UPnP, DLNA, HTTP), a media server for MS Windows, Wine (GNU/Linux), Wineskin on MacOS, featuring individual device settings, transcoding, external and internal subtitles, restricted device access to folders, uploading files, Internet-Radio, Internet-Television, Digital Video Broadcasting (DVB), DMR-control and "Play To", Music (Visualization), Photo (Slideshow), support for 3D-subtitles, support for music fingerprints.
  • Coherence is a framework written in Python to enable applications access to digital living network resources. As a stand-alone application it can act as a UPnP/DLNA media server, in combination with a supported client as a media renderer.
  • AllShare (UPnP, DLNA), a Samsung branded media server for MS Windows. Clients are also available for mobile Android devices. Effective for streaming content over a local network to Samsung devices, notably televisions.
  • KooRaRoo Media (UPnP, DLNA, HTTP), a multimedia organizer and a media server for Windows. On-the-fly transcoding, supports multiple video/audio streams in files, includes a DMS (server) and a DMC (controller) with "play to" functionality. Works with all DLNA-compatible devices.
  • Pixel Media Server is a DLNA compliant Digital Media Server on Android platform. It makes your android Phone/Tablet to DLNA Media Server and publish your media contents (Image/Song/Video) from your Tablet/Phone to the DLNA home network.
  • PLEX Media Server
  • Nero Media Home is a UPnP/DLNA Media Server on the Windows platform, streaming music, videos, photos, and TV shows, It allows to play back your media files on most popular devices including Xbox and PlayStation.
  • ReadyMedia (formerly known as MiniDLNA) is a simple open source media server software, with the aim of being fully compliant with UPnP/DLNA clients.
  • Rygel  is an open source media server software, written in Vala programming language.
